SFP-C59-120-GD-PO
Product Code:
SFP-C59-120-GD-PO
UPC:
SFP-C59-120-GD-PO
Shipping:
Calculated at Checkout
Platform:
MSA
Data Rate:
1G SFP
Optics Class:
1G SFP CWDM
Reach:
120km
Title:
SFP-1G-CWDM-120
Description:
1000Base SFP CWDM EZX 1470-1610nm SMF 120km Transceiver
Qty in Stock:
41
$132.00
SFP, CWDM 1590nm, EZX SMF 120km, 1000Base DDM, Red Bale, MSA Compatible
The Pivotal Optics line of MSA Transceivers ensures complete compatibility and functionality with designated routers and switches, adhering strictly to MSA compliance standards. Each unit undergoes thorough environmental testing in its specific port and platform, meeting all performance requirements for wavelength, distance, density, and light performance. The SFP-C59-120-GD-PO transceiver stands out with an exceptional limited lifetime warranty, surpassing MSA's coverage for the same product.
Download Product Datasheet
SFP, CWDM 1590nm, EZX SMF 120km, 1000Base DDM, Red Bale, MSA Compatible
The Pivotal Optics line of MSA Transceivers ensures complete compatibility and functionality with designated routers and switches, adhering strictly to MSA compliance standards. Each unit undergoes thorough environmental testing in its specific port and platform, meeting all performance requirements for wavelength, distance, density, and light performance. The SFP-C59-120-GD-PO transceiver stands out with an exceptional limited lifetime warranty, surpassing MSA's coverage for the same product.
Download Product Datasheet
Features
- Up to 1.25Gb/s data links
- Up to 120km on 9/125um SMF
- Operating Data Rate up to 1.25Gbps
- 18-Wavelength CWDM DFB LD Transmitter from 1270nm to 1610nm, with Step 20nm
- Single 3.3V Power Supply and TTL Control Logic Interface
- Hot-Pluggable SFP Footprint Duplex LC Connector Interface
- Class 1 FDA and IEC60825-1 Laser Safety Compliant
- Compliant with SFP MSA Specification
- Compliant with SFF-8472 Digital Diagnostic Monitor Interface
- Available operating temperature ranges:
- Commercial: 0°C to 70°C
Applications
- 1000BASE-EZX Ethernet
- OTN / FC
- Other optical links
